亞陶發布超高穩定性低抖動的時鐘振蕩器FD2700036,百利通亞陶公司憑著自身的努力成為實力派制造商,通過自身的奮斗實現了自我的價值,并致力于提供創新的石英晶振產品解決方案，以滿足您的應用需求。我們為消費、通信、計算、核心存儲、連接和顯示技術等主要市場提供對當今設計至關重要的專業知識。Diodes Incorporated為高速信號的定時、開關、橋接和調理提供基本解決方案，滿足當今不斷增長的速度和帶寬要求，如計算機、數字視頻、嵌入式系統、網絡、電信、服務器、存儲、超移動性和無線技術等應用。
| Manufacturer Part Number原廠代碼 | Manufacturer品牌 | Series型號 | Frequency 頻率 | Frequency Stability頻率穩定度 | Operating Temperature 工作溫度 |
| NX3222E0156.250000 | Diodes晶振 | SaRonix-eCera™ NX | 156.25MHz | ±50ppm | -40°C ~ 85°C |
| FN1220025 | Diodes晶振 | SaRonix-eCera™ FN | 12.288MHz | ±50ppm | -40°C ~ 85°C |
| UJ2600003 | Diodes晶振 | SaRonix-eCera™ UJ | 26MHz | ±20ppm | -20°C ~ 70°C |
| JT255CP0026.000000 | Diodes晶振 | SaRonix-eCera™ JT | 26MHz | ±500ppb | -40°C ~ 85°C |
| JT255CP0026.000000 | Diodes晶振 | SaRonix-eCera™ JT | 26MHz | ±500ppb | -40°C ~ 85°C |
| JT255CP0026.000000 | Diodes晶振 | SaRonix-eCera™ JT | 26MHz | ±500ppb | -40°C ~ 85°C |
| FD0670003 | Diodes晶振 | SaRonix-eCera™ FD | 6.7584MHz | ±25ppm | -40°C ~ 85°C |
| FD1300023 | Diodes晶振 | SaRonix-eCera™ FD | 13MHz | ±20ppm | -20°C ~ 70°C |
| FD1300024 | Diodes晶振 | SaRonix-eCera™ FD | 13MHz | ±20ppm | -20°C ~ 70°C |
| FD1430019 | Diodes晶振 | SaRonix-eCera™ FD | 14.31818MHz | ±25ppm | -40°C ~ 85°C |
| FD1940003 | Diodes晶振 | SaRonix-eCera™ FD | 19.44MHz | ±20ppm | -20°C ~ 70°C |
| FD2000047 | Diodes晶振 | SaRonix-eCera™ FD | 20MHz | ±20ppm | -20°C ~ 70°C |
| FD2000051 | Diodes晶振 | SaRonix-eCera™ FD | 20MHz | ±20ppm | -20°C ~ 70°C |
| FD2400026 | 百利通亞陶晶振 | SaRonix-eCera™ FD | 24MHz | ±20ppm | -20°C ~ 70°C |
| FD2500051 | Diodes晶振 | SaRonix-eCera™ FD | 25MHz | ±20ppm | -20°C ~ 70°C |
| FD2500053 | Diodes晶振 | SaRonix-eCera™ FD | 25MHz | ±20ppm | -20°C ~ 70°C |
| FD2500063 | Diodes晶振 | SaRonix-eCera™ FD | 25MHz | ±25ppm | -40°C ~ 85°C |
| FD2600029 | Diodes晶振 | SaRonix-eCera™ FD | 26MHz | ±20ppm | -20°C ~ 70°C |
| FD2600032 | Diodes晶振 | SaRonix-eCera™ FD | 26MHz | ±20ppm | -20°C ~ 70°C |
| FD2600033 | Diodes晶振 | SaRonix-eCera™ FD | 26MHz | ±25ppm | -40°C ~ 85°C |
| FD2700036 | Diodes晶振 | SaRonix-eCera™ FD | 27MHz | ±20ppm | -20°C ~ 70°C |
| FD2700042 | Diodes晶振 | SaRonix-eCera™ FD | 27MHz | ±25ppm | -40°C ~ 85°C |
| FD3300020 | Diodes晶振 | SaRonix-eCera™ FD | 33MHz | ±20ppm | -20°C ~ 70°C |
| FD3330023 | Diodes晶振 | SaRonix-eCera™ FD | 33.333MHz | ±20ppm | -20°C ~ 70°C |
| FD3330025 | Diodes晶振 | SaRonix-eCera™ FD | 33.333333MHz | ±20ppm | -20°C ~ 70°C |
| FD3720001 | Diodes晶振 | SaRonix-eCera™ FD | 37.2MHz | ±20ppm | -20°C ~ 70°C |
| FD3840012 | Diodes晶振 | SaRonix-eCera™ FD | 38.4MHz | ±20ppm | -20°C ~ 70°C |
| FD3840014 | Diodes晶振 | SaRonix-eCera™ FD | 38.4MHz | ±25ppm | -40°C ~ 85°C |
| FD4000106 | Diodes晶振 | SaRonix-eCera™ FD | 40MHz | ±20ppm | -20°C ~ 70°C |
| FD4000136 | Diodes晶振 | SaRonix-eCera™ FD | 40MHz | ±20ppm | -20°C ~ 70°C |
| FD5000038 | Diodes晶振 | SaRonix-eCera™ FD | 50MHz | ±20ppm | -20°C ~ 70°C |
| FD5400016 | Diodes晶振 | SaRonix-eCera™ FD | 54MHz | ±20ppm | -20°C ~ 70°C |
| FD5780001 | Diodes晶振 | SaRonix-eCera™ FD | 57.875MHz | ±20ppm | -20°C ~ 70°C |
| FD7500012 | Diodes晶振 | SaRonix-eCera™ FD | 75MHz | ±20ppm | -20°C ~ 70°C |
| FD8000008 | Diodes晶振 | SaRonix-eCera™ FD | 80MHz | ±25ppm | -20°C ~ 70°C |
| FD8500001 | Diodes晶振 | SaRonix-eCera™ FD | 85MHz | ±25ppm | -20°C ~ 70°C |
| FDA000017 | Diodes晶振 | SaRonix-eCera™ FD | 100MHz | ±50ppm | -20°C ~ 70°C |
| FDA000018 | Diodes晶振 | SaRonix-eCera™ FD | 100MHz | ±25ppm | -20°C ~ 70°C |
| FDA000019 | Diodes晶振 | SaRonix-eCera™ FD | 100MHz | ±50ppm | -40°C ~ 85°C |
| FDA000020 | Diodes晶振 | SaRonix-eCera™ FD | 100MHz | ±50ppm | -40°C ~ 85°C |
| FDA000021 | Diodes晶振 | SaRonix-eCera™ FD | 100MHz | ±50ppm | -40°C ~ 85°C |
有源晶振應用程序
FD系列適用于要求低抖動或緊致的緊湊，高密度應用穩定,包括:以太網,EPON,光纖通道,串行連接SCSI (SAS)m服務器和存儲平臺,SONET/SDH線卡,T1/E1, T3/E3線卡,DSLAM,802.11a/b/g WiFi.亞陶發布超高穩定性低抖動的時鐘振蕩器FD2700036
